Gangchi 5 Ton Cast Iron Counterweight Electric Forklift
Supports multi-dimensional, personalized customization. A standard forklift may not be a perfect fit given varying warehouse ceiling heights, facility aesthetics, and operational workflows.
5 Ton Electric Forklift Truck With Cast Iron Counterweight
Heavy-duty three-wheel electric forklift designed for industrial handling, warehouses and logistics applications. Supporting customized solutions including mast height, body color, battery configuration and accessories.
Customized Electric Forklift Solutions
Our three-wheel electric forklift series supports 1.5-5 ton customized production. The forklift adopts a heavy-duty cast iron counterweight structure, providing excellent stability and load capacity for various working environments.
From warehouse stacking to factory material handling, we provide professional customization solutions based on different customer needs.
Custom Mast Height
Two-stage and three-stage masts available. Customized lifting height for high warehouse operations.
Flexible Color Options
Customized body colors and enterprise exclusive designs available.
Heavy Duty Structure
Integrated reinforced body with excellent durability and stability.
Optional Attachments
Side shifter, load backrest and different battery configurations supported.
Full Customization Service
- ✔ Mast customization: Two-stage and three-stage mast options with customized lifting height.
- ✔ Color customization: Multiple colors available to improve factory identification.
- ✔ Appearance customization: Different forklift exterior designs available.
- ✔ Optional configuration: Side shifter, protective rack and battery options.
Technical Specifications
| Item | Specification |
|---|---|
| Maximum Lifting Capacity | 5000kg |
| Length Without Fork | 3260mm |
| Length With Fork | 4330mm |
| Width | 1400mm |
| Height | 2200mm |
| Vehicle Weight | 5800KG |
| Lifting Height | 3 meters |
| Body Material | Heavy-duty integrated stamped body |
Electrical System
| Driving Motor | 20000W Brushless Variable Frequency AC Motor |
| Voltage | 60V |
| Controller | Anti-slip Slope High Power Controller |
| Battery | 500AN High Capacity Lithium Battery |
| Lighting System | Headlights, Turn Signals, Brake Lights, Dashboard and Horn |
Chassis & Configuration
| Drive Axle | Full Floating Heavy-duty Low Speed Drive Axle |
| Tires | Standard Branded Pneumatic Tires |
| Steering Axle | Heavy-duty Forklift Rear Axle |
| Brake System | Hand Brake and Hydraulic Brake |
| Hydraulic Lifting Motor | 18000W Brushless AC Motor |
| Fork Length | 1070mm Thick Forged Forks |
| Mast Material | Heavy-duty Forklift Special Steel |
| Steering System | Hydraulic Power Steering |
Applications
- Warehouse Material Handling
- Factory Production Lines
- Logistics Centers
- Industrial Storage
- Heavy Load Transportation
- Manufacturing Facilities
